XS Beam B7 7x12W LED Beam Moving Head

• 7PCS CREE 12W 4-IN-1 LEDs (R,G,B,W).
• 60,000 hours life span for LEDs and low power consumption.
• Intelligent temperature sensor for LEDs (over heat protection).
• High efficiency 8 degree optic lens.
• High light output as 840LUX@ 7M at full.
• 0-100% smooth linear dimmer with flicker free.

Add to quote Next Product

Optics:

• Light Source: 7x12W RGBW Kree LEDs

• Total output: 684 lumen@7m

• Life Expectancy: 50,000 h.

• Beam angle: 7°

Effects section:

• 0-100% linear electronic dimmer

• Dimmer frequency is 2000Hz

• Adjustable speed stop/strobe effect, with instantaneous blackout

• Preset color and graphic effect macros

• Dedicated channel for color temperature setting

PAN/TILT

• Very quick linear 540° pan and 270° tilt movements

• 16-Bit Pan/Tilt Positioning, Auto X-Y repositioning

• High precision 3 phase stepping motor control

Connections:

• IEC power connector

• Daisy Chain up to 8 fixtures max (@ 120V); 16 fixtures max (@ 230V)

• Data In/Out socket: 3-pin XLR sockets

• Omega quick lock system bracket

Control:

• DMX protocol signal: USITT DMX 512.

• DMX Channel Modes: 15CH DMX Channels USITT DMX-512. Internal program available.

• Built-in programs with macro effects

• Display: 4-Button 180°reversible LCD colorful Display

SAFETY DEVICES

• Automatic power safety derating in case of overheat of the LED board

Electrical:

• Power Consumption: 300W

• Multi-voltage: 100-240V, 50/60Hz

Dimensions / Weight:

• Dimensions: 15.2x26.5x31cm

• Package: 53x34x30cm

• Net weight: 4.5kg

• Gross weight: 8kg
