D1-380BEAM/PRO 380W Pure Beam Moving Head

 Feature:

350W OSRAM discharge lamp.

Optical Unit with extremely luminous efficiency.

3.8° sharply beam angle.

Very Precise 0-100% dimmer and stop-strobe effect.

Rapid and extensive pan and tilt movements.

Small size & light weight with super bright effect

Over- heat protecting.

Optical

• Light Source: 350W OSRAM discharge lamp

• Color Temperature: 8000 K

• Life Expectancy: 1,500 Hrs.

• Beam Angle: 3.8 degrees

Specifications

• Colors: 14 colors plus white

• Gobos: 17+open fixed gobo

• Dimming: Mechanical dimming 0%- 100%

• Shutter: Pulse effect; random strobe slow to fast

• Focus: motorized

• Frost: frost filter + Prism effect

• Prism: 8-facet linear & 16-facet circular w/ macros, rotating & morphing

PAN/TILT

• Pan/Tilt: 540°/ 270°. Built-In Pan/Tilt Macros

• 16-Bit Pan/Tilt Positioning

• Stepper motors with micro stepping

• Rapid and extensive pan and tilt movements.

Connections

• Power Input: power-CON in/out

• Data: 3-pin DMX in/out XLR

Control

• Control Protocol: DMX 512

• DMX Channels: 19 DMX CH.

• On Board: LED DMX 4-Button menu

Electrical

• Input Voltage: 500watts

• Power draw @120V: 5.2 amps

• Power draw @ 220V: 2.44 amps

• Multi-voltage: 100-240V, 50/60Hz

Dimensions / Weight:

• Dimensions: 56.5x35.5x25CM

• Weight:14.7kg
