L1 SPOT180 180W LED Spot Moving Head

• 180W High Output White LED, 7800K. Spot angle 15°.
• Extremely even spot with flawless field consistency.
• Stepper motors for quick, precise movement.
• Compact size and light weight, easy for installing.
• Super quiet with efficient low noise fan cooling system.

Add to quote Next Product

 Optical:

• Light Source: 180W high output white led, 7800K

• Light output: 51000 LUX @ 2M

• Life Expectancy: 50,000 Hrs.

• Beam Angle: 15 degrees


Specification:

• Outside 25.8mm, inside 21.5mm

• 6+ open custom interchangeable  rotating gobo. indexable and gobo

 shaking

• 8+ open fixed gobos·

• Prism:  6-faced linear 8-facet prism  frost

• Motorized auto focus

• Full range 0-100% dimmer

• Various strobe

• Indicate temperature info of lamp

• Fan speed auto change according to temperature


PAN/TILT

• Pan/Tilt: 540°/ 270°. Built-In Pan/Tilt Macros

• 16-Bit Pan/Tilt Positioning, Auto X-Y repositioning

• Stepper motors with micro stepping

• Rapid and extensive pan and tilt movements


Connections:

• Power Input: Power-CON in/out

•Daisy Chain up to 8 fixtures max (@ 120V); 16 fixtures max (@ 230V)

• Data: 3pin DMX in/out

• Two 1/4 turn fastening Omega Clamps


Control:

• Control Protocol: DMX 512, Master-Slave, Sound, Auto operation and Computer control      software.

• DMX channels:  16

• On Board: 4-Button LCD DMX display


Electrical:

• Power Consumption: 180W

• Multi-voltage: 100-240V, 50/60Hz

• Powercon in and out


Dimensions / Weight:

• Package: 27.5x24.5x35.3cm

• Net weight: 8.3kg

• Gross weight: 9.7kg
